5×5 Toolbar and Hitches
5×5 Standard Hitch
- Not quick hitch compatible
- Free link Cat II & III
- Does not work with center row
- PTO or Hydraulic drive turbofan
- Dry or Liquid Fertilizer optional
5×5 MS Hitch
- Not quick hitch compatible
- Free Link Cat II
- Works with center row unit
- Add up to 6 rows without fertilizer
5×5 Hitch Combo
- Quick Hitch Cat II, III, & 3 Narrow
- Free link Cat II & III
- Works with center row
- Hydraulic drive turbofan only
- Vacuum in top toolbar with 8 rows or more
- Liquid Fertilizer optional
5×5 Advanced Hitch
- Not quick hitch compatible
- Free link Cat II
- PTO or Hydraulic Drive turbofan
- Works with center row unit
- Dry Fertilizer optional
5×5 Double Toolbar Hitch
- Quick Hitch Cat II and III
- Free link Cat II
- Works with center row
- PTO or hydraulic drive turbofan
- Vacuum in top toolbar with 8 rows or more
- Dry Fertilizer optional
7×7 Toolbar and Hitches
7×7 Hitch Combo
- Quick Hitch Cat II & III
- Free link Cat II & III
- Works with center row
- Hydraulic drive turbofan only
- Vacuum in top toolbar with 8 rows or more
- Liquid Fertilizer optional
7×7 Double Toolbar Hitch
- Free link Cat II
- Not quick hitch compatible
- Works with center row
- Hydraulic drive turbofan only
- Vacuum in top toolbar with 8 rows or more
- Dry Fertilizer optional
.
7×7 Stacking Toolbar and Hitches
Air Bar Hitch
- Quick Hitch Cat III & IV
- Free link Cat III & IV
- Works with center row
- Hydraulic drive turbofan only
- Vacuum in toolbar
- Liquid Fertilizer optional
Fully Mounted
- Quick Hitch Cat III & IV
- Free link Cat III & IV
- Works with center row
- Hydraulic drive turbofan only
- Vacuum in toolbar
- Liquid Fertilizer optional
Bauer Bar
- Cat IV hitch
- 45, 60, and 66 foot available
- Not quick hitch compatible
- Hydraulic drive turbofan only
- Hydraulic or Electric drive row units
- Liquid Fertilizer optional
- Central Seed System (CSS) 120 BU optional
5×5 Wheel Blocks
5×5 Fixed Wheel Block
The fixed wheel block is an economical design to properly set the planter to the correct toolbar height without adjustment. This wheel block is for flat ground planting on.
5×5 Adjustable Wheel Block
The 5×5 adjustable wheel block gives the planter the ability to plant on flat or bedded ground. Simplify adjust the knob at the top to extend or retract wheel to maintain proper toolbar height.
7×7 Wheel Blocks
7×7 Positive Drive Wheel Block
The Positive drive wheel block designed so the spring always keeps the wheel in contact with the soil to reduce slippage and skips. With the adjustment on top of the wheel block it makes it quick and easy to go from flat to bedded ground without having to add or take out chain.
7×7 Screw Adjust Wheel Block
The 7×7 adjustable wheel block gives the planter the ability to plant on flat or bedded ground.Simply adjust the threaded rod up or down to set the toolbar height.
7×7 Retro Wheel Block Kit
The retro Wheel block adjustment is designed to work with the 7×7 screw adjust wheel block. The retro kit moves the adjust to the top of the wheel block making it easy to adjust with a wrench or impact tool. Making it fast to switch from flat to bedded ground. With the addition of the spring, it also provides positive contact with the soil for ground drive planters.
Turbofans
Monosem offers three different sizes of turbofans to provide adequate vacuum. based on size of the planter and crops it will be planting. The standard 450 turbofan provides enough vacuum for planters up to 6 rows. The High Output Turbofan is sized to handle planters up to 12 rows. The 500 extra high output turbofan is designed for 12-24 rows and large seeded crops such as peanuts and edible beans. The standard and high output turbofan can be PTO driven with certain hitches.
Turbofan Options
Flow Control
For open center tractors Monosem offers a flow control to adjust the amount of hydraulics being put through the motor. This allows you to set the level of vacuum you desire.
Upload Image...
Anti Drift Dust Kit
The Monosem Anti-Drift kit consists of a collector, a hose, a decompression chamber, and two hoses for redirection of the turbofan exhaust towards the ground. This system steers the air to the ground and decreases the speed, thus limiting the drift of dust from the insecticidal treatment of seeds.
